IMX264やIMX547など、最大2/3インチセンサー用の35mm Cマウントレンズ
35mm Cマウントレンズ 2/3インチ 5MP
CIL526-F1.5-CMANIRは、3.45umピクセルピッチの最大5MP 2/3 "センサー用の高速35mm Cマウントレンズです。絞りはF1.5からF16まで調整可能で、最短撮影距離は200mmです。
In stock — orders before 12 PM PST ship same day
レンズの特徴
8MP解像度
Suitable for 2.74um pixel pitch at F/2.8
“R” Ruggedized Version Available
Build a vibration-resistant computer vision camera..
光学・機械仕様表
| レンズパラメーター | パフォーマンス詳細 |
|---|---|
| 品番 | CIL526 |
| イーエフエル | 35.0 |
| F# | 1.5 |
| 決議 | 8MP (2.74um) |
| 視野 | 17° @ 11.00mm image circle — Calculate FoV for your sensor |
| イメージサークル | 12.8mm |
| ディストーション | レクティリニアから-0.8 |
| 重量 | 122g |
| 建設 | ガラス |
| チーフ・レイ・アングル | 6° |
メカニカル・レイアウト
Frequently asked questions
What sensors work with the CIL526 35mm C-mount lens?
The CIL526 fits 2/3″ sensors including the Sony IMX264 and IMX547 at up to 8MP resolution with 2.74µm pixel pitch. The 12.8mm image circle covers the full 2/3″ format.
What is the difference between CMA and CMR variants of the CIL526?
The CMA variant has an adjustable aperture from F/1.5 to F/16. The CMR variants use fixed apertures and locked mechanical parts, which makes more sense in vibration and shock environments.
What aperture range does the CIL526 offer?
The standard CIL526-F1.5-CMANIR adjusts from F/1.5 to F/16. Ruggedized variants are available at fixed F/1.5, F/2.0, F/2.8, and F/4.0. You can use depth of field calculator to choose the aperture for your working distance.
How much distortion does the CIL526 35mm lens have?
Distortion is -0.8% from rectilinear at the 11mm image circle. That level works for most machine vision inspection and measurement tasks without software correction.
Does the CIL526 ship same day from the US?
Yes, all in-stock CIL526 variants ship same day from San Diego for orders placed before 12 PM PST. Volume pricing starts at 50 units.
What is the minimum working distance of the CIL526?
The minimum working distance is 200mm, measured from the front of the lens to the object plane. The CIL526 focuses from 200mm to infinity.
