IMX541などの最大1.2インチセンサー用25mm Cマウントレンズ
25mm Cマウントレンズ 1.2インチ 25MP
CIL554は、IMX541のようなピクセルピッチ2.74umの25MP 1.2 "センサーフォーマットに対応する25mm Cマウントレンズです。開放F値はF2.8で、F16まで調整可能。
In stock — orders before 12 PM PST ship same day
レンズの特徴
25MP解像度
2.74umピクセルピッチセンサーに最適
調整可能な絞り
F/2.6-F/16の可変絞りにより、最適なパフォーマンスを実現
光学・機械仕様表
| レンズパラメーター | パフォーマンス詳細 |
|---|---|
| 品番 | CIL554 |
| イーエフエル | 25.0 |
| F# | 2.6 |
| 決議 | 25MP, 2.74μm pixel pitch |
| 視野 | 52° @ 19.4mm — Calculate FoV for your sensor |
| イメージサークル | 19.4mm |
| ディストーション | レクティリニアから-0.09 |
| 重量 | 78g |
| 建設 | オールガラス |
メカニカル・レイアウト
Frequently asked questions
What sensors does the CIL554 25mm C-mount lens support?
The CIL554 covers 1.2\" sensors up to 25MP at 2.74μm pixel pitch. The Sony IMX541 is the primary target sensor. The 19.4mm image circle provides full coverage of the 1.2\" format.
What is the distortion on the CIL554?
Distortion is -0.09% from rectilinear — effectively zero. No software distortion correction needed for dimensional measurement, metrology, or precision inspection applications.
What is the CIL554 aperture range?
Adjustable from F/2.6 to F/16. The wide F/2.6 maximum aperture provides good light collection. Stop down for deeper depth of field when inspecting 3D objects or uneven surfaces. Estimate DoF at https://commonlands.com/pages/camera-depth-of-field-calculator.
Does the CIL554 have filter threads?
Yes. M30.5x0.5 front filter thread for standard machine vision filters including bandpass, polarization, and neutral density.
Does the CIL554 ship same day?
Yes. Commonlands ships all in-stock lenses same day from San Diego, California for orders placed before 12 PM PST.
Can I get mechanical drawings for the CIL554?
Yes. Interactive 3D models are on the product page. STP files and detailed mechanical drawings available from engineering@commonlands.com.
